LYNCCN BCY55.88 V8 Press Brake Die with 42CrMo Material and Induction Hardening for Precision Bending
Productdetails
| Productnaam | LYNCCN BCY55.88 V8 kantbank enkele V-matrijsgereedschap | V-opening | V8 |
|---|---|---|---|
| Breedte | 15 mm | Warmtebehandeling | Inductieverharding |
| Hoek | 88° | Hardheid | HRC53±2 |
| Max. Laden | 100T/M | Materiaal | 42CrMo |
| verpakking | HOUTEN KIST | Hoogte | 3000 ton/maand |
| Markeren | LYNCCN BCY55.88 V8 press brake die,single V die tooling for press brake,press brake punch with V8 die |
||
Productomschrijving
LYNCCN BCY55.88 V8 Press Brake Single V Die Tooling
Product Overview
A press brake die is an essential tool used in press brake machines to bend sheet metal into precise angles and shapes. This tooling system consists of a punch (upper tool) and a die (lower tool) that work in tandem to form metal components. The single V die configuration enables various bending techniques including V-bending, U-bending, and hemming operations.
Technical Specifications
| Product Type | Press Brake Single V Die |
|---|---|
| V-opening | V8 |
| Angle | 88° |
| Width | 15mm |
| Height | 75mm |
| Material | 42CrMo |
| Length | 550mm/500mm |
| Hardness | HRC53±2 |
| Heat Treatment | Induction Hardening |
| Max. Load | 100T/M |
| Packing | Wooden Box |
Standard Segmentation Options
500mm
1000mm
1100mm Segmentation
Industry Applications
Our hydraulic CNC press brake tooling is engineered for diverse industrial applications and metal fabrication scenarios. These precision tools are compatible with various press brake machines and are extensively utilized across multiple sectors including aerospace, automotive manufacturing, construction equipment, and shipbuilding industries.
